Working with Comments and Attachments

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
using(SourceCode.Workflow.Client.Connection K2Conn = new Connection()) {
    //simple connection used in this example
    K2Conn.Open("localhost");

    //get a handle on a process instance or worklist item.
    //In this example we will open a worklist item
    WorklistItem _worklistItem = K2Conn.OpenWorklistItem("[SerialNumber]");

    //Add a Comment using the Connection class and the Process Instance ID
    IWorkflowComment comment = K2Conn.AddComment(_worklistItem.ProcessInstance.ID, "Hello World");

    //Add a Comment using the Connection class and the Worklist Item SerialNumber
    IWorkflowComment comment2 = K2Conn.AddComment("[SerialNumber]", "Hello World");

    //Add a Comment using the Connection class and the Process Instance ID and Activity Instance Destination ID
    IWorkflowComment comment3 = K2Conn.AddComment(_worklistItem.ProcessInstance.ID, _worklistItem.ActivityInstanceDestination.ID, "Hello World");

    //Add a Comment using the Process Instance _processInstance = cn.OpenProcessInstance(_processinstanceID);
    IWorkflowComment procInstComment = _worklistItem.ProcessInstance.AddComment("Hello World");

    //Add a Comment using the Worklistltem _worklistItem = cn.OpenWorklistItem(_serialNo);
    IWorkflowComment WLItemComment = _worklistItem.AddComment("Hello World");
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
using(SourceCode.Workflow.Client.Connection K2Conn = new Connection()) {
    //simple connection used in this example
    K2Conn.Open("localhost");

    //get a handle on a process instance or worklist item.
    //In this example we will open a worklist item
    WorklistItem _worklistItem = K2Conn.OpenWorklistItem("[SerialNumber]");

    //Get all the Comments using the Process Instance ID
    IEnumerable < IWorkflowComment > comments1 = K2Conn.GetComments(_worklistItem.ProcessInstance.ID);

    //Get all the Comments using a Worklist Item SerialNumber
    IEnumerable < IWorkflowComment > comments2 = K2Conn.GetComments("[SerialNumber]");

    //Get all the Comments using a Process Instance ID and Activity Instance Destination"s ID
    IEnumerable < IWorkflowComment > comments3 = K2Conn.GetComments(_worklistItem.ProcessInstance.ID, _worklistItem.ActivityInstanceDestination.ID);

    //Get all the Comments from the Process Instance Comments
    IEnumerable < IWorkflowComment > procInstComments = _worklistItem.ProcessInstance.Comments;
    foreach(IWorkflowComment procInstComment in procInstComments) {
        //do something with the comment value
        string comment = procInstComment.Message;
    }

    //Get all the Comments from the Worklist Item Comments
    IEnumerable < IWorkflowComment > wlItemComments = _worklistItem.Comments;
    foreach(IWorkflowComment wlItemComment in wlItemComments) {
        //do something with the comment value
        string comment = wlItemComment.Message;
    }
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
using(SourceCode.Workflow.Client.Connection K2Conn = new Connection()) {
    //simple connection used in this example
    K2Conn.Open("localhost");

    //TODO: stream in the file you want to add.
    //in this example we're loading from the file system
    System.IO.Stream _fileStream = null;
    string _fileName = "[FileName.doc]";
    string fullPath = string.Format(@"C:\Temp\{0}", _fileName);
    //Check if the file exists at the location.
    if (File.Exists(fullPath)) {
        //Get the FileStream
        _fileStream = File.OpenRead(fullPath);
    }

    //get a handle on a process instance or worklist item.
    //In this example we will open a worklist item
    WorklistItem _worklistItem = K2Conn.OpenWorklistItem("[SerialNumber]");

    //Add an Attachment using the Connection class and the Process Instance ID
    IWorkflowAttachment attachment1 = K2Conn.AddAttachment(_worklistItem.ProcessInstance.ID, _fileName, _fileStream);

    //Add an Attachment using the Connection class and the Worklist Item SerialNumber
    IWorkflowAttachment attachment2 = K2Conn.AddAttachment("[SerialNumber]", _fileName, _fileStream);

    //Add an Attachment using the Connection class and the Process Instance ID and Activity Instance Destination ID
    IWorkflowAttachment attachment3 = K2Conn.AddAttachment(_worklistItem.ProcessInstance.ID, _worklistItem.ActivityInstanceDestination.ID, _fileName, _fileStream);

    //Add an Attachment using the Process Instance
    IWorkflowAttachment ProcInstAttachment = _worklistItem.ProcessInstance.AddAttachment(_fileName, _fileStream);

    //Add an Attachment using the Worklistltem
    IWorkflowAttachment WLItemAttachment = _worklistItem.AddAttachment(_fileName, _fileStream);
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
using(SourceCode.Workflow.Client.Connection K2Conn = new Connection()) {
    //simple connection used in this example
    K2Conn.Open("localhost");

    //TODO: stream in the file you want to add.
    //in this example we're loading from the file system
    System.IO.Stream _fileStream = null;
    string _fileName = "[FileName.doc]";
    string fullPath = string.Format(@"C:\Temp\{0}", _fileName);
    //Check if the file exists at the location.
    if (File.Exists(fullPath)) {
        //Get the FileStream
        _fileStream = File.OpenRead(fullPath);
    }

    //get a handle on a process instance or worklist item.
    //In this example we will open a worklist item
    WorklistItem _worklistItem = K2Conn.OpenWorklistItem("[SerialNumber]");

    //Add an "empty" attachment without the file content by passing null as the content
    //This approach can be used for async purposes
    //to create the attachment metadata first, and then upload the file.
    IWorkflowAttachment attachmentWithoutContent = K2Conn.AddAttachment(_worklistItem.ProcessInstance.ID, _fileName, null);
    //Upload the actual file content
    //Note: You can only upload the file once for an "empty" attachment.
    IAttachment attachmentWithContent = K2Conn.UploadAttachmentContent(attachmentWithoutContent.Id, _fileStream);
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
using(SourceCode.Workflow.Client.Connection K2Conn = new Connection()) {
    //simple connection used in this example
    K2Conn.Open("localhost");

    //get a handle on a process instance or worklist item.
    //In this example we will open a worklist item
    WorklistItem _worklistItem = K2Conn.OpenWorklistItem("[SerialNumber]");

    //Get all the Attachments using the Process Instance ID
    //By default this call will always return the attachment files.
    IEnumerable < IWorkflowAttachment > attachments1 = K2Conn.GetAttachments(_worklistItem.ProcessInstance.ID);

    //Get all the Attachments using the SerialNumber
    //By default this call will always return the attachment files.
    IEnumerable < IWorkflowAttachment > attachments2 = K2Conn.GetAttachments("[SerialNumber]");

    //Get all the Attachments using the Process Instance ID and Activity Instance Destination ID
    //By default this call will always return the attachment"s files.
    IEnumerable < IWorkflowAttachment > attachments3 = K2Conn.GetAttachments(_worklistItem.ProcessInstance.ID, _worklistItem.ActivityInstanceDestination.ID);

    //Get all the Attachments from the Process Instance "Attachments" property
    IEnumerable < IWorkflowAttachment > procInstAttachments = _worklistItem.ProcessInstance.Attachments;

    //Get all the Attachments from the Worklist Item "Attachments" property
    _worklistItem = K2Conn.OpenWorklistItem("[SerialNumber]");
    IEnumerable < IWorkflowAttachment > wlitemAttachments = _worklistItem.Attachments;

    //once you have retrieved the attachments, you can iterate over them
    foreach(IWorkflowAttachment attachment in wlitemAttachments) {
        string filename = attachment.FileName;
    }
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
using(SourceCode.Workflow.Client.Connection K2Conn = new Connection()) {
    //simple connection used in this example
    K2Conn.Open("localhost");

    //get a handle on a process instance or worklist item.
    //In this example we will open a worklist item
    WorklistItem _worklistItem = K2Conn.OpenWorklistItem("[SerialNumber]");

    //Get all the Attachments using the Process Instance ID
    //pass "false" for the includeFile parameter to only load the file on demand.
    IEnumerable < IWorkflowAttachment > attachments1 = K2Conn.GetAttachments(_worklistItem.ProcessInstance.ID, false);

    //Get all the Attachments using the SerialNumber
    //pass "false" for the includeFile parameter to only load the file on demand.
    IEnumerable < IWorkflowAttachment > attachments2 = K2Conn.GetAttachments("[SerialNumber]", false);

    //Get all the Attachments using the Process Instance ID and Activity Instance Destination ID
    //pass "false" for the includeFile parameter to only load the file on demand.
    IEnumerable < IWorkflowAttachment > attachments3 = K2Conn.GetAttachments(_worklistItem.ProcessInstance.ID, _worklistItem.ActivityInstanceDestination.ID, false);

    //once you have retrieved the attachments, you can iterate over them
    foreach(IWorkflowAttachment attachment in attachments3) {
        string filename = attachment.FileName;
        //use the attachment.GetFile() method to load the attachments file
        using(System.IO.Stream downloadStream = attachment.GetFile()) {
            //do something with the downloaded filestream
        }
    }
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
using(SourceCode.Workflow.Client.Connection K2Conn = new Connection()) {
    //simple connection used in this example
    K2Conn.Open("localhost");

    int _attachmentID = 1;
    //Get the Attachment by passing the Attachment ID
    //By default, this call will always return the attachment file content.
    IWorkflowAttachment attachment = K2Conn.GetAttachment(_attachmentID);

    //to load the file content on-demand, pass "false" for the includeFile parameter.
    IWorkflowAttachment attachmentNoFile = K2Conn.GetAttachment(_attachmentID, false);
    //when ready, get the file content
    System.IO.Stream _fileStream = attachmentNoFile.GetFile();
}
