Salesforce (Legacy) Service

K2 integrates with Salesforce.com through the Salesforce (Legacy) Service Service Type. One can register an instance of this broker that points to a Salesforce account, which exposes entities within that company as Service Objects. The service requires a WSDL file provided by Salesforce. Before a Service Instance can be registered for the Salesforce Service, it needs to be generated. This is done by using the Broker Manager - see the topic Configure Salesforce Integration for more information and guidance on registering a Salesforce (Legacy) Service Instance.

The screenshots and instructions for third-party software are accurate at the time of writing. Third-party vendors may have changed or updated aspects of their systems (such as user interfaces, functionality, and security). As a result, this content may be outdated.

Service Authentication

Single Sign-On (SSO) is the only supported Authentication Mode for a Salesforce (Legacy) Service Instance.

Service Keys (Service Instance Configuration Settings)

Key Can be modified Data Type Sample Value Notes
wsdlname Yes Text SourceCode.SalesForce.WSDL.SalesForce.dll Enter the Sales Force wsdl name.
deletepath Yes Text C:\SalesForce Schema\ Enter the delete path.
querypath Yes Text C:\SalesForce Schema\ Enter a query path.
updatename Yes Text SourceCode.SalesForce.UpdateFromXML.SalesForce.dll Enter the update name.
createpath Yes Text C:\SalesForce Schema\ Enter the create path.
MSNETSFproptypemap Yes Text <object type="SourceCode.SmartObjects.Services.ServiceSDK.Objects. TypeMappings"> <typemappings><mapping name= "System.Object" sotype="memo" /><mapping name= "System.String" sotype="text" /><mapping name= "System.Double" sotype="number" /><mapping name= "System.Int64" sotype="number" /><mapping name= "System.Boolean" sotype="yesno" /><mapping name= "System.Byte[]" sotype="memo" /><mapping name= "System.Int16" sotype="number" /><mapping name= "System.Int32" sotype="number" /><mapping name= "System.DateTime" sotype="datetime" /><mapping name= "System.Decimal" sotype="decimal" /></typemappings> </object> Defines the type mappings that convert SalesForce data types to equivalent K2 Service Object data types.
updatepath Yes Text C:\SalesForce Schema\ Enter an update path.
metapath Yes Text C:\SalesForce Schema\ Enter the meta path.
deletename Yes Text SourceCode.SalesForce.DeleteFromXML.SalesForce.dll Enter the delete name.
wsdlpath Yes Text C:\SalesForce Schema\ Enter the WSDL path.
queryname Yes Text SourceCode.SalesForce.QueryFromXML.SalesForce.dll Enter the query name.
metaname Yes Text SourceCode.SalesForce.MetaFromXML.SalesForce.dll Enter the meta name.
createname Yes Text SourceCode.SalesForce.CreateFromXML.SalesForce.dll Enter the create name.

Service Objects

K2 will generate Service Objects as defined in the WSDL file obtained from Salesforce for the targeted Salesforce environment .

SmartObjects

SmartObjects can be automatically created by selecting the Generate SmartObjects for this Service Instance check box when creating a new Service Instance. Designers can use the SmartObject design tools to build advanced SmartObjects that leverage the Service Objects in this service. It is recommended to use the SmartObject design tools to create SmartObjects rather than generating SmartObjects, since this allows better control over the naming, behavior and design of the SmartObject and its methods and properties.

Considerations

  • Before the service instance can be registered and used, it needs to be generated. This is done by using the Broker Manager utility. See the topic Configure Salesforce Integration for more information.

  • The Instance destination path should be a short path with no spaces or ( ) in it, as these characters will cause an error.

  • If you need to update a SmartObject with updates from Salesforce, it needs to be done using a Salesforce account which has Salesforce admin rights.
